PANELO WALLS FOR MULTI-STORY BUILDINGS
PANELO FIRE-RESISTANT WALL PANELS FOR MULTI STORY BUILDINGS
NO MOISTURE, NO DAMP INSIDE STRUCTURES.
2 side cement boards
- panel is load bearing (wooden frame inside)
- panel is covered with cement board (fire class A1 or A2) from outside
- panel is covered with cement board (A1 or A2) from inside
- measures 3 x 12 m (max), custom sizes available
1 side cement board
- panel is load bearing (wooden frame inside)
- covered with cement board (fire class A1 or A2) from one side
- covered with OSB or LVL from other side
- measures 3 x 12 m (max), custom sizes available
Extreme PANELO
- panel is load bearing (LVL frame inside)
- covered with LVL board and cement board (fire class A1 or A2) from outside
- covered with LVL board and cement board (A1 or A2) from inside
- measures 3 x 12 m (max), custom sizes available
PANELO fire resistant sandwich panels are similar to SIP panels, but technically much more complex. PANELO panels consist of wooden frame, closed-cell PUR insulation and Cement boards on one or both sides. The closed-cell insulation foam is inserted into panels in liquid mode with special technology and therefor leaves no air gaps.
Panels will be produced according to any project’s requirements – measures, U values and loads. PANELO panels meet low-energy and passive house standards with thin structures. This means more neto m2-s for your building.
SAMPLE MEASURES, OSB and LVL boards can be substituted with cement boards
| No | Panel (layers mm) | Thick. (mm) | U-value W/(m²K) |
|---|---|---|---|
| 10 | FP 15-145-12 (OSB-PUR-Cembrit) | 172 | 0,18 |
| 11 | FP 15-170-12 (OSB-PUR-Cembrit) | 197 | 0,16 |
| 12 | FP 15-195-12 (OSB-PUR-Cembrit) | 222 | 0,14 |
| 13 | FP 15-220-12 (OSB-PUR-Cembrit) | 247 | 0,13 |
| 14 | FP 15-245-12 (OSB-PUR-Cembrit) | 272 | 0,11 |
| 15 | FP 21-145-12 (LVL-PUR-Cembrit) | 178 | 0,18 |
| 16 | FP 21-170-12 (LVL-PUR-Cembrit) | 203 | 0,16 |
| 17 | FP 21-195-12 (LVL-PUR-Cembrit) | 228 | 0,14 |
| 18 | FP 21-220-12 (LVL-PUR-Cembrit) | 253 | 0,12 |
| 19 | FP 21-245-12 (LVL-PUR-Cembrit) | 278 | 0,11 |
| No | Panel (layers mm) | Thick. (mm) | U-value W/(m²K) |
|---|---|---|---|
| 7 | EW 15-120-15 (MgO-PUR-OSB) | 150 | 0,22 |
| 8 | EW 15-145-15 (MgO-PUR-OSB) | 175 | 0,18 |
| 9 | EW 15-170-15 (MgO-PUR-OSB) | 200 | 0,16 |
| 10 | EW 15-195-15 (MgO-PUR-OSB) | 225 | 0,14 |
| 11 | EW 15-220-15 (MgO-PUR-OSB) | 250 | 0,13 |
| 12 | EW 15-245-15 (MgO-PUR-OSB) | 275 | 0,11 |
| 13 | EW 15-120-15 (MgO-PUR-MgO) | 150 | 0,22 |
| 14 | EW 15-145-15 (MgO-PUR-MgO) | 175 | 0,19 |
| 15 | EW 15-170-15 (MgO-PUR-MgO) | 200 | 0,16 |
| 16 | EW 15-195-15 (MgO-PUR-MgO) | 225 | 0,14 |
| 17 | EW 15-220-15 (MgO-PUR-MgO) | 250 | 0,13 |
| 18 | EW 15-245-15 (MgO-PUR-MgO) | 275 | 0,11 |
PANELO STRUCTURAL WALL PANELS
